Del Nordlund
PROG14998
Object-Oriented Toy
21 October 2016

Help the robot to avoid the falling ladders! Be careful, they vary in height!
A - Move Left
D - Move Right
*/

//Create a new bot object
Bot botty = new Bot();
//Create an array of 9 ladders
Ladder[] ladders = new Ladder[9];
//The game is not over yet, so the gameOver variable is false.
boolean isGameOver = false;

void setup()
{
  //set window size
  size (500, 400);
  smooth();
  noCursor();
  noStroke();
  //prints instructions to the bottom of the screen
  println("Use A and D to move the robot and avoid the falling ladders!");
  //for loop creates ladder objects and inputs their speed
  for(int i = 0; i < ladders.length; i++)
  {
    ladders[i] = new Ladder(3);
  }
}

void draw()
{
  background(247, 173, 173);
  //moves the bot and draws it to the screen
  botty.moveBot();
  botty.drawBot();
  //makes each ladder fall and display it to the screen
  for(int i = 0; i < ladders.length; i++)
  {
    ladders[i].ladderFall();
    ladders[i].drawLadder();
    //check if ladder has been hit
    ladders[i].checkHit();
    //check if the game is over
    gameOver();
  }
}

//for when the game ends
void gameOver()
{
  //once gameOver is true
  if (isGameOver == true)
  {
    //draws a game over screen with text "Game Over"
    fill(255);
    rect(250, 190, 501, 421);
    fill(247, 173, 173);
    rect(width/2, height/2, 300, 200);
    fill(0);
    textAlign(CENTER);
    textSize(24);
    text("G A M E\nO V E R", width/2, height/2);
  }
}
//BOT CLASS

//create a float variable for x position of bot
float botX;

class Bot
{
  //constructor for bot
  Bot()
  {
    //bot starts in the middle of the screen
    botX = 250;
  }

  void drawBot()
  {
    //Draw the bot to the screen when called upon.
    ellipseMode(CENTER);
    rectMode(CENTER);
    //draws hover
    fill(249, 249, 77);
    ellipse(botX, 350+sin(millis()/100)*2, 30, 20);
    fill(255, 127);
    ellipse(botX, 350+sin(millis()/100)*2, 40, 30);
    fill(175, 175);
    ellipse(botX+sin(millis()/100)*2, 380, 50, 10);
    //draws body and neck
    fill(0);
    rect(botX, 330+sin(millis()/100)*2, 50, 50);
    rect(botX, 305+sin(millis()/100)*2, 30, 20);
    //draws head and ears
    rect(botX, 285+sin(millis()/100)*2, 50, 30);
    triangle(botX-25, 273+sin(millis()/100)*2, botX-15, 260+sin(millis()/100)*2, botX-5, 273+sin(millis()/100)*2);
    triangle(botX+25, 273+sin(millis()/100)*2, botX+15, 260+sin(millis()/100)*2, botX+5, 273+sin(millis()/100)*2);
    //draw eyes
    fill(255, 127);
    ellipse(botX-15, 285+sin(millis()/100)*2, 15, 15);
    fill(255, 255, 150);
    ellipse(botX-15, 285+sin(millis()/100)*2, 10, 10);
    fill(255, 127);
    ellipse(botX+15, 285+sin(millis()/100)*2, 15, 15);
    fill(255, 255, 150);
    ellipse(botX+15, 285+sin(millis()/100)*2, 10, 10);
  }

  void moveBot()
  //moves the bot when called upon. if the 'a' key is pressed, move left, if 'd' key is pressed, move right.
  //if the bot exceeds the screen boundaries, make it pop up on the other side.
  {
    if (keyPressed)
    {
      if (key == 'a' || key == 'A')
      {
        if (botX + 25 < 0)
        {
          botX = 510;
        }
        else
        {
          botX = botX - 5;
        }
      }
      if (key == 'd' || key == 'D')
      {
        if (botX - 25 > 500)
        {
          botX = -10;
        }
        else
        {
          botX = botX + 5;
        }
      }
      this.drawBot();
    }
  }
}
//LADDER CLASS

class Ladder
{
  //PVectors for ladder position and velocity, floats for length of the ladders and their speed
  PVector ladderPos = new PVector();
  PVector ladderVelo = new PVector();
  float ladderLength;
  float ladderSpeed;

  //Ladder constructor
  Ladder(float ladderSpeed)
  {
    //ladders can be a limited number of pixels long.
    ladderLength = random(39, 251);
    //ladders begin at random x position
    ladderPos.x = random(1, 499);
    //ladders spawn out of view and fall into view
    ladderPos.y = 0 - ladderLength;
    //ladders fall at this speed
    ladderVelo.y = ladderSpeed;
  }

  void drawLadder()
  {
    fill(173, 151, 107);
    //draw 2 length pieces
    rect(ladderPos.x, ladderPos.y, 5, ladderLength);
    rect(ladderPos.x+20, ladderPos.y, 5, ladderLength);
    //draw steps based on how long the ladder is
    rect(ladderPos.x+10, ladderPos.y, 20, 5);
    if (ladderLength > 55)
    {
      rect(ladderPos.x+10, ladderPos.y-25, 20, 5);
      rect(ladderPos.x+10, ladderPos.y+25, 20, 5);
      if (ladderLength > 110)
      {
        rect(ladderPos.x+10, ladderPos.y-50, 20, 5);
        rect(ladderPos.x+10, ladderPos.y+50, 20, 5);
        if (ladderLength > 205)
        {
          rect(ladderPos.x+10, ladderPos.y-75, 20, 5);
          rect(ladderPos.x+10, ladderPos.y+75, 20, 5);
          if (ladderLength > 240)
          {
            rect(ladderPos.x+10, ladderPos.y-100, 20, 5);
            rect(ladderPos.x+10, ladderPos.y+100, 20, 5);
          }
        }
      }
    }
  }

  //causes the ladders to fall
  void ladderFall()
  {
    //add velocity to position of ladder
    ladderPos.add(ladderVelo);
    //if the ladder falls out of view of the user
    if (ladderPos.y-ladderLength > 500)
    {
      //respawn ladder at the top with different x coordinates and a different length
      ladderPos.y = 0 - ladderLength;
      ladderPos.x = random (1, 499);
      ladderLength = random (9, 251);
    }
  }

  //checks if ladders have been hit
  void checkHit()
  {
    //if ladder falls within bot boundaries
    if (ladderPos.x >= (botX-25) && ladderPos.x <= (botX+25) || (ladderPos.x+20) >= (botX-25) && (ladderPos.x+20) <= (botX+25))
    {
      if ((ladderPos.y-(ladderLength/2)) > 260 && (ladderPos.y+(ladderLength/2)) < 355)
      {
        //set game over to true
        isGameOver = true;
      }
    }
  }
}
