//state variables int ball1x = 100; int ball1y = 150; int ball2x= 150; int ball2y= 80; int ball3x = 300; int ball3y = 70; int ball4x = 270; int ball4y = 120; boolean isFoodFilled; boolean ball1= false; boolean ball2= false; boolean ball3= false; boolean ball4= false; int milliseconds = (int) millis(); int milliseconds2 = (int) millis(); int randomTime = (int)random(1, 5); int reset = 0; //resets milliseconds int reset2 = 0; //setup method void setup(){size(400, 400);} //draw method void draw (){ //draw the bg drawBG(); //draw the back objects bodyDraw(); //draw the head depending on if the food is filled or the balls are played with if (isFoodFilled){drawEatHead();} else if (ball1 || ball2 ||ball3 ||ball4){drawMotionHead();} else{drawNeutralHead();} //draw the balls drawBalls(); //run the foreground method cageDraw(); } //method to draw the eating head //as well as using the timer to have the head stay in place void drawEatHead(){ //if the timer is still true, or the animation is supposed to be shown, show the eating bird if (timer (90) == true){ fill(100, 100, 255); quad(211, 158, 185, 163, 181, 177, 173, 148); ellipse(195 -25, 130 + 36, 40, 40); triangle (178 -25, 119 + 36, 220 -25, 80 + 36, 208 -25, 122 + 36); fill (100); triangle (180-25, 118 + 36, 170- 25, 148 + 36, 197 - 25, 147 + 36); fill (240); ellipse(200- 25, 127 + 36, 10, 20); fill(100, 100, 255); rect (194- 25, 132 + 36, 15, 10); fill (200, 150, 50); rect(130, 184, 50, 5); } //when the timer is done, empty the food bin else {isFoodFilled = false;} } //method to draw the neutral head with the blink void drawNeutralHead(){ //get the value of milliseconds milliseconds2 = (int) millis() - reset; //draw the head noStroke(); fill(100, 100, 255); quad(185, 143, 208, 146, 206, 160, 189, 162); ellipse(195, 130, 40, 40); triangle (178, 119, 220, 80, 208, 122); fill (100); triangle (180, 118, 170, 148, 197, 147); fill (240); //have the eyes blink randomly //if it blinks, reset the millisecond counter to 0, and generate a new random number if (milliseconds2 >= randomTime){ //if the timer is true, draw the eyes for the animation. when the timer is over, THEN make alterations to variables. if (timer(5) == true){ellipse (200, 127, 10, 3);} else{randomTime = (int)random(1000, 5000); reset = reset + milliseconds2 + 5;}} //if it is not blinking, draw the eye normally else{ellipse(200, 127, 10, 20); }} //method to draw the head looking at the balls void drawMotionHead(){ //draw the static neck noStroke(); fill(100, 100, 255); quad(185, 143, 208, 146, 206, 160, 189, 162); ellipse(195, 130, 40, 40); //draw the head looking depending on which ball is moving if (ball1){ // the red one triangle (178, 119, 220, 80, 208, 122); fill(100); triangle(160, 146, 179, 119, 185, 146); fill (255); ellipse(190, 127, 10, 20); } if (ball2){ // the green one triangle (213, 126, 233, 167, 206, 146); fill (100); triangle(167, 101, 174, 130, 192, 110); fill (255); ellipse (189, 125, 10, 20);} if (ball3){ // the blue one triangle (178, 118, 164, 160, 194, 145); fill (100); triangle (201, 109, 227, 105, 213, 135); fill (255); ellipse (192, 120, 10, 20); } if (ball4){ //the yellow one triangle (200, 110, 156, 99, 178, 135); fill (100); triangle (209, 118, 233, 131, 208, 144); fill (255); ellipse (202, 126, 10, 20); } } //method to draw the cage void cageDraw(){ strokeWeight (3); stroke(100); fill(100); for (int i = 0; i < 7; i++){ line (80 + (40*i), 40, 80 + (40*i), 320); } strokeWeight(6); line (30, 20, 30, 400); line (30, 20, 200, 20); line (200, 20, 200, 40); line (80, 40, 320, 40); rect(80, 320, 240, 20); quad(60, 360, 80, 340, 320, 340, 340, 360); } //draw the balls and chords void drawBalls(){ stroke(0); strokeWeight(2); line(100, 40, ball1x, ball1y); line(150, 40, ball2x, ball2y); line(300, 40, ball3x, ball3y); line(270, 40, ball4x, ball4y); ellipseMode(CENTER); noStroke(); fill(255, 0, 0); ellipse(ball1x, ball1y, 20, 20); fill (0, 255, 0); ellipse(ball2x, ball2y, 20, 20); fill(0, 0, 255); ellipse(ball3x, ball3y, 20, 20); fill (255, 255, 0); ellipse(ball4x, ball4y, 20, 20);} //method to draw the bg void drawBG(){ //draw the bg background(232, 210, 215); fill(100, 0, 0); noStroke(); rect(0, 300, 400, 100);} //method to draw static objects void bodyDraw(){ //draw the birds static body- wing, base, wing noStroke(); fill(80, 80, 255); quad(175, 160, 170, 190, 190, 235, 195, 190); fill(100, 100, 255); quad(182, 162, 210, 158, 225, 220, 190, 220); ellipse(205, 215, 30, 35); quad(200, 200, 200, 255, 235, 295, 235, 242); fill(80, 80, 255); quad(210, 150, 200, 186, 228, 230, 232, 190); //draw the birds pedestal and the food box stroke(100); strokeWeight(9); line(150, 250, 150, 320); line(150, 250, 230, 250); strokeWeight(4); stroke(150); fill(180); rect(130, 190, 50, 30); //if the mouse is hovering over the food box, light it up if (mouseX > 130 && mouseX < 180 && mouseY > 190 && mouseY < 220){ fill (255, 50); rect(130, 190, 50, 30);} //draw the feet noStroke(); fill(125); quad(195, 225, 190, 240, 195, 246, 200, 228); quad(208, 224, 207, 244, 215, 245, 215, 224); ellipse(190, 248, 18, 18); ellipse(212, 248, 18, 18); } //if the mouse is clicked on the food bin, fill it with food void mousePressed(){ if (mouseX > 130 && mouseX < 180 && mouseY > 190 && mouseY < 220){ isFoodFilled = true; }} //if the mouse is dragged where a ball is, move the ball around within a restricted domain and return a boolean that says // that the ball is, indeed, being moved. void mouseDragged(){ if (mouseX>80 && mouseX < 120 && mouseY>130 && mouseY< 170){ ball1x = mouseX; ball1y = mouseY; ball1= true; ball2 = false; ball3 = false; ball4 = false; } if(mouseX>130 && mouseX < 170 && mouseY>60 && mouseY< 100){ ball2x = mouseX; ball2y = mouseY; ball1= false; ball2 = true; ball3 = false; ball4 = false;} if(mouseX>280 && mouseX < 320 && mouseY>50 && mouseY< 90){ ball3x = mouseX; ball3y = mouseY; ball1= false; ball2 = false; ball3 = true; ball4 = false;} if(mouseX>250 && mouseX < 290 && mouseY>100 && mouseY< 140){ ball4x = mouseX; ball4y = mouseY; ball1= false; ball2 = false; ball3 = false; ball4 = true;}} //when the mouse is released, reset the balls to their normal location void mouseReleased(){ ball1x = 100; ball1y = 150; ball2x= 150; ball2y= 80; ball3x = 300; ball3y = 70; ball4x = 270; ball4y = 120; ball1 = false; ball2 = false; ball3 = false; ball4 = false; } //create a timer that lasts for a specified amount of time in methods it's used in boolean timer(int length){ milliseconds = millis() - reset2; if (millis() - milliseconds < length){ reset2= reset2 + 1; return true;} else {reset2 = 0; return false;}}
