//Author: Pamela Payad //
//Ice Cream Scooper //
//1. Click on the ice cream flavour you want. //
//2. Click on the toppings you want. //
//3. Click on the cone that is faced down to restart your cone.//
/////////////////////////////////////////////////////////////////
//set variables
int toppingsContainer=30;
int iceCreamBucket=30;
int iceCream=60;
int iceCreamBucket2 = 30;
float sprinklesR = random(200);
float sprinklesG = random(200);
float sprinklesB = random(200);
//set up the window
void setup() {
size(400, 400);
noStroke();
fill(100);
//run background drawing function
drawBackground();
}
void draw() {
//chocolate
drawIceCreamCone();
drawIceCream(118, 80, 4, 45);
//vanilla
drawIceCream(250, 244, 232, 165);
//strawberry
drawIceCream(255, 216, 216, 285);
//draw the cone
drawIceCreamCone();
//draw the topping displays
drawCherry(95, 60, 110, 60);
drawCherry(115, 60, 130, 60);
drawCherry(95, 80, 110, 80);
drawCherry(115, 80, 130, 80);
drawSprinkles();
drawWafer();
drawChocChips();
//update functions
chooseFlavour();
chooseTopping();
restartCone();
}
//draw the background with no updates
void drawBackground() {
noStroke();
//toppingsContainer counter//
fill(220);
rect(0, 0, 260, 240);
fill(230);
rect(10, 0, 260, 230);
fill(190);
rect(20, 20, 230, 200, 5);
fill(203);
rect(40, 130, 180, 80, 5);
fill(234);
rect(45, 130, 180, 80, 5);
//make a loop for the background of each topping "container"
for (toppingsContainer=30; toppingsContainer< 220; toppingsContainer=toppingsContainer+55) {
fill(178);
rect(toppingsContainer, 35, 40, 80, 5);
}
//ice cream counter//
fill(200);
rect(260, 0, 260, 400);
fill(210);
rect(270, 0, 270, 390);
//make a loop for the background of each topping "bucket"
for (iceCreamBucket=30; iceCreamBucket< 290; iceCreamBucket=iceCreamBucket+120) {
fill(196);
rect(285, iceCreamBucket, 100, 100, 5);
}
for (iceCreamBucket2=30; iceCreamBucket2< 290; iceCreamBucket2=iceCreamBucket2+120) {
fill(196);
rect(285, iceCreamBucket2, 100, 100, 5);
}
//table top//
fill(100);
rect(0, 240, 260, 180);
fill(150);
rect(10, 250, 240, 180, 5);
fill(180);
rect(15, 255, 235, 175, 5);
//cones display
fill(191, 161, 100);
triangle(30, 400, 70, 400, 50, 340);
fill(222, 187, 116);
triangle(35, 400, 70, 400, 54, 350);
noStroke();
fill(0, 101, 162);
rect(230, 370, 15, 60);
ellipse(237, 370, 35, 35);
fill(0, 74, 118);
ellipse(235, 370, 20, 27);
}
// draw regular ice cream cone without ice cream
void drawIceCreamCone() {
//ice cream cone//
fill(191, 161, 100);
triangle(60, 200, 140, 460, 200, 200);
fill(222, 187, 116);
triangle(70, 200, 150, 470, 200, 200);
}
//draw an ice cream scooper that follows that mouse
void drawIceCreamScoop(int iceR, int iceG, int iceB) {
noStroke();
fill(iceR, iceG, iceB);
ellipse(132, 170, 140, 140);
for (iceCream=60; iceCream< 240; iceCream=iceCream+140) {
fill(iceR, iceG, iceB);
ellipse(iceCream, 180, 40, 40);
}
//ice cream cone//
fill(191, 161, 100);
triangle(60, 200, 140, 460, 200, 200);
fill(222, 187, 116);
triangle(70, 200, 150, 470, 200, 200);
}
//makes the squares for the ice cream
//parameters needed are the colour and y position
void drawIceCream(int flavourR, int flavourG, int flavourB, int iceY) {
noStroke();
fill(flavourR, flavourG, flavourB);
rect(300, iceY, 75, 75, 5);
}
//draw the cherry display with the parameters of the positions of the cherries
void drawCherry(int cherryX, int cherryY, int stemX, int stemY) {
stroke(85, 0, 21);
fill(185, 0, 15);
ellipse(cherryX, cherryY, 12, 12);
noFill();
arc(stemX, stemY, 30, 30, PI, PI+QUARTER_PI);
}
//draw the display for the wafer
void drawWafer() {
noStroke();
fill(216, 195, 109);
rect(145, 50, 12, 40);
fill(216, 195, 109);
rect(160, 35, 12, 40);
fill(255, 226, 147);
rect(147, 50, 10, 40);
fill(255, 226, 147);
rect(162, 35, 10, 40);
}
//draw the diplay of the chocolate chips
void drawChocChips() {
stroke(96, 68, 0);
fill(116, 83, 0);
triangle(220, 65, 225, 60, 230, 65);
triangle(210, 55, 215, 50, 220, 55);
triangle(200, 45, 205, 40, 210, 45);
triangle(220, 85, 225, 80, 230, 85);
triangle(210, 75, 215, 70, 220, 75);
triangle(200, 65, 205, 60, 210, 65);
triangle(220, 105, 225, 100, 230, 105);
triangle(210, 95, 215, 90, 220, 95);
triangle(200, 85, 205, 80, 210, 85);
}
//draw the diplay of the chocolate sprinkles
void drawSprinkles() {
stroke(sprinklesR, sprinklesG, sprinklesB);
line(40, 50, 50, 53);
stroke(sprinklesR+90, sprinklesG-8, sprinklesB);
line(60, 63, 65, 70);
stroke(sprinklesR+23, sprinklesG-55, sprinklesB);
line(30, 70, 40, 60);
stroke(sprinklesR+3, sprinklesG+55, sprinklesB+90);
line(40, 100, 30, 90);
stroke(sprinklesR+32, sprinklesG+57, sprinklesB-90);
line(45, 80, 35, 90);
stroke(sprinklesR+50, sprinklesG+5, sprinklesB-26);
line(55, 90, 60, 80);
}
//draw topping functions for when they are chosen//
void sprinkles() {
stroke(sprinklesR, sprinklesG, sprinklesB);
line(100, 140, 110, 130);
stroke(sprinklesR+100, sprinklesG-90, sprinklesB);
line(120, 110, 130, 120);
stroke(sprinklesR-100, sprinklesG-90, sprinklesB);
line(150, 150, 160, 140);
stroke(sprinklesR+10, sprinklesG-90, sprinklesB);
line(140, 130, 150, 125);
stroke(sprinklesR+130, sprinklesG+90, sprinklesB);
line(110, 150, 120, 145);
}
void chocChips() {
stroke(96, 68, 0);
fill(116, 83, 0);
triangle(115, 120, 120, 110, 130, 120);
triangle(90, 140, 100, 130, 110, 140);
triangle(160, 130, 170, 120, 175, 130);
triangle(140, 140, 150, 130, 160, 140);
triangle(135, 110, 140, 100, 145, 110);
}
void cherry() {
noStroke();
fill(124, 1, 11);
ellipse(130, 100, 30, 30);
fill(185, 0, 15);
ellipse(130, 100, 27, 27);
stroke(85, 0, 21);
noFill();
arc(160, 90, 60, 60, PI, PI+QUARTER_PI);
}
void wafer() {
noStroke();
fill(216, 195, 109);
quad(165, 75, 190, 100, 160, 150, 135, 135);
fill(255, 226, 147);
quad(170, 80, 190, 100, 160, 150, 140, 140);
}
//choose the topping here
void chooseTopping() {
noStroke();
if (mousePressed) {
if (mouseX > 80 && mouseX < 130 && mouseY > 40 && mouseY < 120) {
cherry();
} else if (mouseX > 130 && mouseX < 170 && mouseY > 40 && mouseY < 120) {
wafer();
} else if (mouseX > 30 && mouseX < 170 && mouseY > 40 && mouseY < 120) {
sprinkles();
} else if (mouseX > 180 && mouseX < 230 && mouseY > 40 && mouseY < 120) {
chocChips();
}
}
}
//detects when the chosen flavour is clicked
void chooseFlavour() {
noStroke();
if (mousePressed) {
//detect when the mouse is over the ice cream and run the ice cream function and colours in the parameters specified in the parameters
if (mouseX> 300 && mouseX < 380 && mouseY > 40 && mouseY < 120) {
drawIceCreamScoop(118, 80, 4);
} else if (mouseX> 300 && mouseX < 380 && mouseY > 140 && mouseY < 240) {
drawIceCreamScoop(250, 244, 232);
} else if (mouseX> 300 && mouseX < 380 && mouseY > 270 && mouseY <360) {
drawIceCreamScoop(255, 216, 216);
}
}
}
//when user clicks on the cone, the background properties are redrawn
void restartCone() {
if (mousePressed) {
//detect when the mouse is over the ice cream and run the ice cream function and colours in the parameters specified in the parameters
if (mouseX> 40 && mouseX < 80 && mouseY > 340 && mouseY < 400) {
drawBackground();
//run background drawing function
drawBackground();
//chocolate
drawIceCreamCone();
drawIceCream(118, 80, 4, 45);
//vanilla
drawIceCream(250, 244, 232, 165);
//strawberry
drawIceCream(255, 216, 216, 285);
//draw the cone
drawIceCreamCone();
//draw the topping displays
drawCherry(95, 60, 110, 60);
drawCherry(115, 60, 130, 60);
drawCherry(95, 80, 110, 80);
drawCherry(115, 80, 130, 80);
drawSprinkles();
drawWafer();
drawChocChips();
}
}
}
