int polarFlip = 1;
float aPos = 315;
float bPos = 315;
float cPos = 315;
float dPos = 265;
float ePos = 265;
float fPos = 265;
float gPos = 315;

void setup(){
  size(400,400);
  smooth();
}

void draw(){
  background(0,0,0);
  bodyRender();
  waveRender(35,262,100);
  switchRender();
  holoRender();
}

float wave(float xPos){

  ////////////////////////////////////////////////////////
  // Calculates Y Position of Given X Value in Waveform //
  ////////////////////////////////////////////////////////

  float y = 0;
  if(polarFlip == 1){

    // Toggles Which Wave Advances With Time

    y = ((aPos-280)/1.6)*((float)(Math.cos(((bPos-270)*0.88)*xPos+(frameCount/8))))+100+((cPos-280)/1.6)*((float)(Math.sin(10*xPos)))+100;
  }
  else{
    y = ((aPos-280)/1.6)*((float)(Math.cos(((bPos-270)*0.88)*xPos)))+100+((cPos-280)/1.6)*((float)(Math.sin(10*xPos+(frameCount/8))))+100;
  }
  return y;
}

void waveRender(float xShift, float yShift, float scale){

  ///////////////////////////////
  // Draws Screen and Waveform //
  ///////////////////////////////

  noStroke();
  fill((dPos-252),(ePos-252),(fPos-252));
  beginShape();
  vertex(xShift,yShift+(scale/20));
  vertex(xShift+(scale/20), yShift);
  vertex(xShift+scale-(scale/20), yShift);
  vertex(xShift+scale, yShift+(scale/20));
  vertex(xShift+scale, yShift+scale-(scale/20));
  vertex(xShift+scale-(scale/20), yShift+scale);
  vertex(xShift+(scale/20), yShift+scale);
  vertex(xShift, yShift+scale-(scale/20));
  endShape(CLOSE);
  fill((dPos-252)*3,(ePos-252)*3,(fPos-252)*3);
  ellipseMode(CORNER);
  ellipse(xShift,yShift,scale,scale);
  for(int i=0; i<400; i=i+10){
    strokeWeight(2);
    stroke((dPos-252)*10,(ePos-252)*10,(fPos-252)*10);
    line(i/(400/scale)+xShift,wave(i)/(400/scale)+yShift,(i+10)/(400/scale)+xShift,wave(i+10)/(400/scale)+yShift);
  }
  strokeWeight(2);
  stroke((dPos-252)*10,(ePos-252)*10,(fPos-252)*10,150);
  line(xShift+(scale/4), yShift+(scale/2), xShift+(scale-(scale/4)), yShift+(scale/2));
  line(xShift+(scale/2), yShift+(scale/4), xShift+(scale/2), yShift+(scale-(scale/4)));
}

float dialShift(float xPos, float yPos, float xRange, float yRange, float pos, boolean axis){ // bounds of dial, current state, indicator axis of movement (true = y)

  ////////////////////////////////////////////////////////////////
  // Checks if a Dial has Been Clicked, and Adjusts Accordingly //
  ////////////////////////////////////////////////////////////////

  float shift = 0;
  if(mouseX >= xPos && mouseX <= xRange && mouseY >= yPos && mouseY <= yRange){
    if (axis == true){
      shift = mouseY - pos;
    }
    else{
      shift = mouseX - pos;
    }
  }
  return shift;
}

boolean buttonToggle(float xPos, float yPos, float xRange, float yRange){
  if(mouseX >= xPos && mouseX <= xRange && mouseY >= yPos && mouseY <= yRange){
    return true;
  }
  else{
    return false;
  }
}

void switchRender(){

  //////////////////////////////////
  // Draws the Holotron Interface //
  //////////////////////////////////

  noStroke();
  fill(32,32,32);
  rectMode(CORNERS);
  rect(149,279,151,351);
  rect(174,279,176,351);
  rect(199,279,201,351);
  rect(297,275,299,350);

  fill(100,100,100);
  rectMode(CENTER);
  rect(150,aPos,16,6);
  rect(175,bPos,16,6);
  rect(200,cPos,16,6);
  rect(298,gPos,16,6);
  ellipseMode(CENTER);
  ellipse(265,280,30,30);
  ellipse(265,315,30,30);
  ellipse(265,350,30,30);
  fill(175,175,175);
  ellipse(dPos,(float)(0.077*Math.pow((dPos-265),2)+267),4,4);
  ellipse(ePos,(float)(0.077*Math.pow((ePos-265),2)+302),4,4);
  ellipse(fPos,(float)(0.077*Math.pow((fPos-265),2)+337),4,4);

  fill(100,100,100);
  ellipse(225,350,18,18);
  fill(255,30,16);
  ellipse(225,350,10,10);

  rectMode(CORNERS);
  fill(100,100,100);
  rect(310,265,335,360);
  fill(245,245,170);
  rect(314,269,331,356);
  fill(100,100,100,150);
  rect(320,272,331,273);
  rect(325,282,331,283);
  rect(320,292,331,293);
  rect(325,302,331,303);
  rect(320,312,331,313);
  rect(325,322,331,323);
  rect(320,332,331,333);
  rect(325,342,331,343);
  rect(320,352,331,353);
  fill(255,30,16);
  rect(314,gPos-1,327,gPos+1);
}

void holoRender(){

  ////////////////////////
  // Draws the Hologram //
  ////////////////////////

  int opacity = (int)(225-random(abs(200-((gPos-265)*4)+20)));
  float scale = bPos-250;
  float moonX = (float)(1.4*scale*sin(PI*frameCount/(aPos-260)+PI*((cPos-315)/35))+200);
  float moonY = (float)(0.7*scale*Math.sin(PI*frameCount/(aPos-260))+100);
  float R = ePos + fPos - 504;
  float G = dPos + fPos - 504;
  float B = dPos + ePos - 504;
  if(polarFlip == 1){
    fill((dPos-252)*6,(ePos-252)*6,(fPos-252)*6,opacity/2);
  }
  else{
    fill(R*3,G*3,B*3,opacity/2);
  }
  quad(50,200,(200-1.25*scale),100,200,(100-0.5*scale),200,(100+0.5*scale));
  quad(350,200,200,(100+0.5*scale),200,(100-0.5*scale),(200+1.25*scale),100);
  triangle(50,200,moonX-0.075*scale,moonY,moonX+0.075*scale,moonY);
  triangle(350,200,moonX-0.075*scale,moonY,moonX+0.075*scale,moonY);
  ellipseMode(CENTER);
  if(polarFlip == 1){
    fill((dPos-252)*10,(ePos-252)*10,(fPos-252)*10,opacity);
  }
  else{
    fill(R*5,G*5,B*5,opacity);
  }
  arc(200,100,scale,scale,0,PI);
  if(polarFlip == 1){
    fill((dPos-252)*8,(ePos-252)*8,(fPos-252)*8,opacity);
  }
  else{
    fill(R*4,G*4,B*4,opacity);
  }
  ellipse(200,100,2.5*scale,scale/2);
  ellipse(moonX,moonY,0.15*scale,0.15*scale);
  if(polarFlip == 1){
    fill((dPos-252)*10,(ePos-252)*10,(fPos-252)*10,opacity);
  }
  else{
    fill(R*5,G*5,B*5,opacity);
  }
  arc(200,100,scale,scale,PI,2*PI);
  arc(200,100,scale,scale/10,0,PI);
}

void bodyRender(){

  ////////////////////////////////////
  // Draws the Body of the Holotron //
  ////////////////////////////////////

  fill(150,150,150);
  triangle(50,200,200,235,200,250);
  triangle(350,200,200,235,200,250);
  fill(100,100,100);
  ellipse(200,250,70,60);
  ellipse(50,200,15,15);
  ellipse(350,200,15,15);
  fill(235,228,190);
  beginShape();
  vertex(25,365);
  vertex(25,260);
  vertex(35,250);
  vertex(365,250);
  vertex(375,260);
  vertex(375,365);
  vertex(365,375);
  vertex(35,375);
  endShape(CLOSE);
}

void mousePressed(){

  //////////////////////////////////////
  // Checks if any Dials were Pressed //
  //////////////////////////////////////

  aPos = aPos + dialShift(142,280,158,350,aPos,true);
  bPos = bPos + dialShift(167,280,183,350,bPos,true);
  cPos = cPos + dialShift(192,280,208,350,cPos,true);
  dPos = dPos + dialShift(252,267,277,283,(int)dPos,false);
  ePos = ePos + dialShift(252,302,277,318,(int)ePos,false);
  fPos = fPos + dialShift(252,337,277,353,(int)fPos,false);
  gPos = gPos + dialShift(290,275,306,350,gPos,true);
  if(buttonToggle(220,345,230,355)){
    polarFlip = -polarFlip;
  }
}
