Smashed by Suraj Sirohi
Use arrrow keys, left and right to move the hook horizontally and up and down for vertical movement.
Try to hook the reddish box, once hooked the box will turn dark.
Press Shift to drop the box anywhere (Once Hooked).
Dropping the box directly aboive the person will smash the person.
After the person is crushed under the box you can pick up the box again, the person will respawn.
*/
float cranePosX = 200 ;
float craneSpeed = 6;
float craneStringEndPoint = 150;
float boxPosX = 300, boxPosY = 340;
float fallingSpeed = 2;
float personPosX = 200, personPosY = 350;
float boomEffectRadius;
float boomEffectAlpha = 255;
float bloodDropPosX, bloodDropPosY;
float bloodDropRadius = 15;
float bloodPoolRadius, bloodPoolRadiusExpandSpeed = 2;
float unitsMoved;
float personHeight = 20;
float randomNumber;
float personSpeed = 0.5;
int bloodPoolAlpha = 255;
int hookedColor = 166;
boolean checkForHook = true, Hooked;
boolean doGenerateRandomNumber;
boolean personAlreadySmashed;
boolean movePersonBool;
boolean createBloodPoolBool;
boolean randomNumberGenerated;
boolean speak;
void setup() {
size(400, 400);
}
void draw() {
background(124, 225, 255);
//Make cloud pattern
makeClouds();
//Draw Ground
drawGround();
//Draw Crane Rod
drawCraneRod();
//Draw Crane String
drawCraneString();
//Draw Person
drawPerson();
//Hook the PickUpBox to Crane String when close enough
lookForHook();
//Move the PickUpBox wth crane when Hooked
postHooked();
//Generate a random number once
generateRandomNumber();
//Make the PickUpBox Fall
boxDrop();
//Reset The smash bool
resetSmashingBooleans();
//Animate Respawning
respawnPerson();
//Call screateBloodPool function
if (createBloodPoolBool) {
createBloodPool();
}
//Spread The Blood
spreadBlood();
//Draw Crane Box
Crane();
//Draw Blue Box
drawPickUpBox();
//Constraint Y-position of PickUpBox
constraintBoxPosition();
//Smash the person when box falls directly on it.
startSmashPersonProcess();
//Reset Smashing
resetSmash();
//Move Person In Random Directions
if (movePersonBool && unitsMoved < 40) {
movePerson();
unitsMoved+=0.1;
}
//Make Person Speak
makePersonSpeak();
}
void keyPressed() {
if (key == CODED) {
if (keyCode == LEFT && cranePosX > 169) {
cranePosX -= craneSpeed;
} else if ( keyCode == RIGHT) {
cranePosX += craneSpeed;
}
if (keyCode == UP && craneStringEndPoint > 120) {
craneStringEndPoint -= craneSpeed;
} else if (keyCode == DOWN && craneStringEndPoint < 340) {
craneStringEndPoint += craneSpeed;
}
if (keyCode == SHIFT) {
Hooked =false;
hookedColor=166;
}
}
}
//Draw Ground
void drawGround() {
rectMode(CORNER);
fill(100, 100, 0);
rect(0, 360, 400, 50);
}
//Draw Crane Long rod
void drawCraneRod() {
strokeWeight(9);
stroke(252, 237, 79);
line(64, 324, cranePosX, 70);
}
//Draw Crane Strings
void drawCraneString() {
//Strings
strokeWeight(2);
line(cranePosX -3, 70, cranePosX-3, craneStringEndPoint - 20);
line(cranePosX +3, 70, cranePosX+3, craneStringEndPoint - 20);
noStroke();
//Joint Circle
fill(252, 237, 79);
ellipse(cranePosX -2, 72, 15, 15);
//Hook Base
quad(cranePosX -2, craneStringEndPoint -22, cranePosX +2, craneStringEndPoint -22, cranePosX +5, craneStringEndPoint -16, cranePosX -5, craneStringEndPoint-16);
quad(cranePosX -5, craneStringEndPoint - 16, cranePosX + 5, craneStringEndPoint -16, cranePosX + 2, craneStringEndPoint - 1, cranePosX - 2, craneStringEndPoint - 1);
//Hook
stroke(252, 237, 79);
noFill();
arc(cranePosX, craneStringEndPoint + 7, 15, 15, PI + 1.6, 2*PI + 2);
}
//Draw the Crane Box
void Crane() {
rectMode(CORNER);
noStroke();
//Yellow Back Box
fill(252, 237, 79);
rect(20, 312, 50, 40);
//Black Front Box
fill(40);
rect(30, 302, 40, 40);
//Sky Color Window
fill(149, 231, 255);
rect(35, 307, 30, 30);
//Black Wheels
strokeWeight(15);
stroke(40);
line(20, 355, 70, 355);
//Inner Wheels
strokeWeight(7);
stroke(100);
line(20, 355, 70, 355);
noStroke();
}
//Draw Box to be picked up by Crane
void drawPickUpBox() {
//Main Box
rectMode(CENTER);
fill(hookedColor, 113, 142);
rect(boxPosX, boxPosY, 50, 40);
//In-Between Lines
stroke(hookedColor, 59, 126);
strokeWeight(4);
line(boxPosX - 24, boxPosY -18, boxPosX - 24, boxPosY +18);
line(boxPosX - 12, boxPosY -18, boxPosX - 12, boxPosY +18);
line(boxPosX - 2, boxPosY -18, boxPosX - 2, boxPosY +18);
line(boxPosX + 8, boxPosY -18, boxPosX + 8, boxPosY +18);
line(boxPosX + 22, boxPosY -18, boxPosX + 22, boxPosY +18);
noStroke();
}
//Draw Humanoid Character
void drawPerson() {
noStroke();
//Main Rect
fill(153, 188, 104);
rectMode(CENTER);
rect(personPosX, personPosY, 15, personHeight);
//Pants
fill(245, 128, 70);
rect(personPosX, personPosY + 6, 15, 10);
stroke(126, 66, 38);
line(personPosX, personPosY, personPosX, personPosY +10);
noStroke();
//Head
fill(255, 227, 82);
ellipse(personPosX, personPosY - 15, personHeight/1.2, personHeight/1.2);
fill(103, 76, 19);
arc(personPosX, personPosY - 18, personHeight/1.2, personHeight/1.2, PI, 2*PI);
}
//Mask the reddish blood pool
void drawBloodPoolMask() {
fill(124, 225, 255);
rect(personPosX, personPosY, 220, 20);
}
//Crush the person under the box
void smashPerson() {
personHeight = 0;
fill(250, 130, 80, boomEffectAlpha);
ellipse(personPosX, personPosY, boomEffectRadius, boomEffectRadius);
boomEffectRadius += 10;
boomEffectAlpha -= 10;
fill(255, 0, 0);
ellipse(personPosX + bloodDropPosX, personPosY + bloodDropPosY, bloodDropRadius, bloodDropRadius);
ellipse(personPosX + bloodDropPosX + 20, personPosY + bloodDropPosY + 7, bloodDropRadius, bloodDropRadius);
ellipse(personPosX + bloodDropPosX - 20, personPosY + bloodDropPosY + 2, bloodDropRadius, bloodDropRadius);
bloodDropPosY -= 4;
bloodDropRadius -= 0.7;
}
//Create Blood pool that spreads after person is smashed
void createBloodPool() {
fill(232, 93, 75, bloodPoolAlpha);
ellipse(personPosX, personPosY + 10, bloodPoolRadius, 10);
if (bloodPoolRadiusExpandSpeed > 0) {
bloodPoolRadius += bloodPoolRadiusExpandSpeed;
}
bloodPoolRadiusExpandSpeed -= 0.01;
}
//Reset values after smashing
void resetSmashing() {
personAlreadySmashed = true;
boomEffectAlpha = 255;
boomEffectRadius = 0;
bloodDropRadius = 15;
bloodDropPosY = 0;
unitsMoved = 0;
randomNumberGenerated=false;
}
//Make person move in random direction
void movePerson() {
if (personPosX > 149 && personPosX < 385) {
if (randomNumber > 1) {
personPosX += personSpeed;
} else {
personPosX -= personSpeed;
}
} else if (personPosX <= 149) {
personPosX += personSpeed;
} else if (personPosX >= 185) {
personPosX -= personSpeed;
}
}
//Print a statement when perons is crushed
void personSpeak() {
println("Ouch!");
}
//Make CLoud Pattern
void makeClouds() {
for (int k = 0; k < 9; k++) {
for (int j =0; j < 4; j++) {
for (int i = 0; i < 4; i++) {
fill(152, 251, 255);
ellipse(40 * i/1.7 + k *120 + j*35 - 90, 20 + j * 50, 30, 25);
}
}
}
}
void lookForHook() {
if (abs(boxPosX - cranePosX) < 4 && abs(craneStringEndPoint - boxPosY) < 4 && checkForHook) {
hookedColor = 120;
Hooked = true;
checkForHook =false;
}
}
void postHooked() {
if (Hooked) {
boxPosX = cranePosX;
boxPosY = craneStringEndPoint;
if (!randomNumberGenerated) {
doGenerateRandomNumber = true;
}
}
}
void generateRandomNumber() {
if (doGenerateRandomNumber) {
randomNumber = random(2);
doGenerateRandomNumber = false;
randomNumberGenerated = true;
}
}
void boxDrop() {
if (!Hooked && boxPosY < 338) {
boxPosY += fallingSpeed;
fallingSpeed += 0.25;
}
}
void resetSmashingBooleans() {
if (boxPosY < 300) {
personAlreadySmashed = false;
movePersonBool = true;
if (bloodPoolAlpha >0) {
bloodPoolAlpha -= 8;
} else {
bloodPoolRadius = 0;
bloodPoolRadiusExpandSpeed = 2;
}
}
}
void respawnPerson() {
if (personHeight < 20 && boxPosY < 300) {
personHeight++;
}
}
void constraintBoxPosition() {
if (boxPosY >= 338) {
checkForHook =true;
fallingSpeed =2;
boxPosY =340;
movePersonBool =false;
}
}
void startSmashPersonProcess() {
if (abs(personPosX - boxPosX) < 26 && abs(personPosY - boxPosY) < 15 && !personAlreadySmashed && !Hooked) {
bloodPoolAlpha=255;
smashPerson();
personSpeak();
}
}
void resetSmash() {
if (boomEffectAlpha < 5) {
resetSmashing();
}
}
void makePersonSpeak() {
if (speak) {
personSpeak();
speak = false;
}
}
void spreadBlood() {
if (personAlreadySmashed) {
createBloodPoolBool =true;
drawBloodPoolMask();
}
}
