////////////IMC Project 1 Interactive Drawing//////////// /* By: Lawrence Le Prof: Fredd Eyles For: Intro to Media Computation Date: 20 September 2017 */ /* - Vertical Mouse Movement Controls 4 Lamps > Lights Turn On/Off > Light Hitting The Ground Around Lamps > Stone Lamps Get Brighter From The Light - Horizonal Mouse Movement Controls Clouds and Moon > Brightens/Darkens Entire Area > Sky Gets Brighter > Clouds Move Out Of The Way And Dissipate > Moon Shines Brighter - Moving The Mouse Cursor Will Move The Firefly - Mouse Click To Make Crow's Eye Flash Red > Framerate Lowered To 3 During Click - Key Press To Make Firefly Sparkle > Framerate Lowered To 3 During Press - Stars Twinkle */ void setup() { //Setting Window Size size(400, 400); } void draw() { //Background Colour background(0); //Setting FrameRate frameRate(30); ////////////CODE FOR SKY//////////// //Sky Colour fill(25, 25, 80 + mouseX/50); rectMode(CENTER); rect(200, 100, 400, 200); fill(25, 25, 70, 255 - mouseX/2); rect(200, 60, 400, 125); fill(25, 25, 60, 255 - mouseX/2); rect(200, 20, 400, 100); //Moon fill(230); ellipseMode(CENTER); ellipse(50, 50, 60, 60); //Moonlight fill(240, 0 + mouseX/10); ellipse(50, 50, 70, 70); fill(255, 0 + (mouseX/10)*0.5); ellipse(50, 50, 85, 85); //Clouds fill(200, 220 - mouseX*0.6); ellipseMode(CENTER); ellipse(60 + mouseX/10, 60, 80 + mouseX/25, 30 - mouseX/35); ellipse(55 + mouseX/10, 75, 25 + mouseX/20, 15 - mouseX/40); ellipse(45 - mouseX/4, 65, 60, 25 - mouseX/35); ellipse(55 - mouseX/6, 30, 100 + mouseX/30, 20); //ellipse (175 + mouseX/12, 50, 125 + mouseX/35, 35 - mouseX/30); ////////////CODE FOR GRASS//////////// //Grass Colour (Below Walkway) noStroke(); fill(70, 110 + mouseX*0.04, 70); rectMode(CENTER); rect(200, 375, 400, 100); //Blades of Grass (Below Walkway) fill(75, 125 + mouseX*0.04, 75); triangle(75, 385, 72, 372, 81, 385); fill(80, 140 + mouseX*0.04, 80); triangle(80, 385, 83, 367, 86, 385); fill(77, 133 + mouseX*0.04, 77); triangle(84, 385, 103, 377, 92, 385); fill(80, 140 + mouseX*0.04, 80); triangle(290, 385, 293, 367, 296, 385); fill(75, 125 + mouseX*0.04, 75); triangle(297, 385, 294, 372, 303, 385); fill(77, 133 + mouseX*0.04, 77); triangle(175, 395, 172, 382, 181, 395); fill(80, 140 + mouseX*0.04, 80); triangle(160, 395, 163, 377, 166, 395); fill(77, 133 + mouseX*0.04, 77); triangle(164, 395, 183, 387, 172, 395); //Grass Colour (Above Walkway) noStroke(); fill(75, 120 + mouseX*0.04, 75); rectMode(CENTER); rect(200, 220, 400, 125); //Blades of Grass (Above Walkway) fill(85, 130 + mouseX*0.04, 85); triangle(200, 220, 200, 205, 193, 220); fill(90, 140 + mouseX*0.04, 90); triangle(193, 220, 189, 210, 185, 220); fill(88, 135 + mouseX*0.04, 88); triangle(192, 220, 194, 203, 195, 220); fill(90, 140 + mouseX*0.04, 90); triangle(70, 170, 68, 163, 64, 170); fill(85, 130 + mouseX*0.04, 85); triangle(68, 169, 60, 164, 62, 169); //Grass-Sky Cut-off stroke(25); strokeWeight(5); line(0, 158, 100, 158); strokeWeight(4); line(100, 157, 180, 157); strokeWeight(5); line(180, 159, 310, 159); strokeWeight(3); line(310, 157, 400, 157); ////////////CODE FOR TREE + CROW//////////// //Dead Tree fill(30 + mouseX*0.04, 20, 20); noStroke(); rectMode(CORNERS); rect(340, 40, 365, 200); rect(300, 85, 340, 95); rect(260, 88, 300, 97); triangle(365, 200, 365, 160, 370, 200); triangle(340, 160, 335, 130, 340, 100); triangle(340, 100, 340, 95, 325, 95); triangle(260, 88, 260, 97, 256, 94); triangle(300, 97, 300, 95, 309, 95); triangle(300, 88, 300, 85, 292, 88); triangle(365, 40, 365, 95, 368, 60); quad(340, 40, 350, 40, 355, 0, 350, 0); quad(340, 40, 348, 40, 330, 0, 326, 0); quad(340, 55, 340, 43, 313, 0, 307, 0); quad(350, 40, 358, 40, 365, 0, 359, 0); quad(356, 40, 366, 42, 450, 10, 459, 0); rect(320, 20, 325, 0); rect(385, 30, 392, 0); triangle(340, 200, 340, 192, 290, 200); triangle(355, 200, 362, 200, 359, 205); quad(358, 200, 370, 198, 376, 203, 381, 208); //Crow fill(0); ellipse(296, 75, 26, 10); ellipse(284, 70, 11, 11); triangle(280, 67, 280, 73, 268, 70); stroke(0); strokeWeight(2); line(300, 79, 302, 82); line(302, 82, 301, 85); line(301, 85, 298, 86); quad(286, 71, 301, 71, 318, 80, 316, 80); quad(286, 71, 301, 71, 317, 77, 315, 77); ////////////CODE FOR WALKWAY//////////// //Walkway stroke(150 + mouseX*0.04); strokeWeight(100); line(0, 302, 400, 302); //Walkway Squares stroke(120 + mouseX*0.04); strokeWeight(6); line(0, 254, 400, 254); line(-25, 347, 25, 256); line(75, 347, 125, 256); line(68, 347, 125, 256); line(175, 347, 225, 256); line(168, 347, 225, 256); line(275, 347, 325, 256); line(268, 347, 325, 256); line(375, 347, 425, 256); line(368, 347, 425, 256); strokeWeight(12); line(0, 347, 400, 347); strokeWeight(9); line(0, 299, 400, 299); ////////////CODE FOR LAMP 1//////////// //Removing Outlines noStroke(); //Lamp 1 Light on Ground fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(75, 355, 80, 15); fill(255, 255, 0, 0 + (mouseY/12)*0.35); ellipse(75, 355, 130, 25); //Lamp 1 Lightbulb fill(200 + (mouseY/8), 200 + (mouseY/8), 0); ellipse(75, 285, 15, 15); //Lamp 1 fill(80 + mouseY/20); rectMode(CENTER); rect(75, 350, 50, 10); fill(110 + mouseY/20); rect(75, 320, 20, 35); fill(100 + mouseY/20); rect(75, 300, 40, 10); fill(90 + mouseY/16); rect(75, 290, 45, 10); fill(120 + mouseY/20); rect(75, 320, 12, 23); fill(90 + mouseY/20); rect(75, 340, 40, 10); fill(90 + mouseY/20); triangle(52, 285, 62, 265, 62, 285); triangle(88, 285, 88, 265, 98, 285); //Lamp 1 Light ellipseMode(CENTER); fill(255, 255, 0, 0 + (mouseY/12)); ellipse(75, 285, 30, 30); fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(75, 285, 60, 60); fill(255, 255, 0, 0 + (mouseY/12)*0.4); ellipse(75, 285, 100, 100); ////////////CODE FOR LAMP 2////////////// //Lamp 2 Light on Ground fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(275, 355, 80, 15); fill(255, 255, 0, 0 + (mouseY/12)*0.35); ellipse(275, 355, 130, 25); //Lamp 2 Lightbulb fill(200 + (mouseY/8), 200 + (mouseY/8), 0); ellipse(275, 285, 15, 15); //Lamp 2 fill(80 + mouseY/20); rect(275, 350, 50, 10); fill(110 + mouseY/20); rect(275, 320, 20, 35); fill(100 + mouseY/20); rect(275, 300, 40, 10); fill(90 + mouseY/20); rect(275, 290, 45, 10); fill(120 + mouseY/20); rect(275, 320, 12, 23); fill(90 + mouseY/20); rect(275, 340, 40, 10); fill(90 + mouseY/20); triangle(252, 285, 262, 265, 262, 285); triangle(288, 285, 288, 265, 298, 285); //Lamp 2 Light fill(255, 255, 0, 0 + (mouseY/12)); ellipse(275, 285, 30, 30); fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(275, 285, 60, 60); fill(255, 255, 0, 0 + (mouseY/12)*0.4); ellipse(275, 285, 100, 100); ////////////CODE FOR LAMP 3//////////// //Lamp 3 Light on Ground fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(125, 254, 64, 12); fill(255, 255, 0, 0 + (mouseY/12)*0.35); ellipse(125, 254, 104, 20); //Lamp 3 Lightbulb fill(160 + (mouseY/8), 160 + (mouseY/8), 0); ellipse(125, 194, 12, 12); //Lamp 3 fill(65 + mouseY/20); rect(125, 250, 40, 8); fill(95 + mouseY/20); rect(125, 224, 20, 28); fill(85 + mouseY/20); rect(125, 206, 32, 8); fill(75 + mouseY/20); rect(125, 198, 36, 8); fill(105 + mouseY/20); rect(125, 224, 10, 19); fill(75 + mouseY/20); rect(125, 242, 32, 8); fill(75 + mouseY/20); triangle(107, 194, 115, 178, 115, 194); triangle(135, 194, 135, 178, 143, 194); //Lamp 3 Light fill(255, 255, 0, 0 + (mouseY/12)); ellipse(125, 194, 24, 24); fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(125, 194, 48, 48); fill(255, 255, 0, 0 + (mouseY/12)*0.4); ellipse(125, 194, 80, 80); ////////////CODE FOR LAMP 4//////////// //Lamp 4 Light on Ground fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(325, 254, 64, 12); fill(255, 255, 0, 0 + (mouseY/12)*0.35); ellipse(325, 254, 104, 20); //Lamp 4 Lightbulb fill(160 + (mouseY/8), 160 + (mouseY/8), 0); ellipse(325, 194, 12, 12); //Lamp 4 fill(65 + mouseY/20); rect(325, 250, 40, 8); fill(95 + mouseY/20); rect(325, 224, 16, 28); fill(85 + mouseY/20); rect(325, 206, 32, 8); fill(75 + mouseY/16); rect(325, 198, 36, 8); fill(105 + mouseY/20); rect(325, 224, 10, 19); fill(75 + mouseY/20); rect(325, 242, 32, 8); fill(75 + mouseY/20); triangle(307, 194, 315, 178, 315, 194); triangle(335, 194, 335, 178, 343, 194); //Lamp 4 Light fill(255, 255, 0, 0 + (mouseY/12)); ellipse(325, 194, 24, 24); fill(255, 255, 0, 0 + (mouseY/12)*0.75); ellipse(325, 194, 48, 48); fill(255, 255, 0, 0 + (mouseY/12)*0.4); ellipse(325, 194, 80, 80); ////////////CODE FOR GLOWING LIGHTS//////////// //Stars fill(255, 255, 200, 200); ellipse(200, 100, sin(frameCount/16)*3, 10); ellipse(200, 100, 10, sin(frameCount/16)*3); ellipse(120, 60, sin(frameCount/20)*2, 8); ellipse(120, 60, 8, sin(frameCount/20)*2); ellipse(50, 125, sin(frameCount/16)*3, 9); ellipse(50, 125, 9, sin(frameCount/16)*3); ellipse(300, 40, sin(frameCount/20)*2, 10); ellipse(300, 40, 10, sin(frameCount/20)*2); ellipse(380, 140, sin(frameCount/16)*3, 8); ellipse(380, 140, 8, sin(frameCount/16)*3); //Firefly Light fill(255, 255, 0, 40); ellipse(mouseX, mouseY, 25, 25); fill(255, 255, 0, 75); ellipse (mouseX, mouseY, sin(frameCount/10)*15, sin(frameCount/10)*15); fill(255, 255, 0, 100); ellipse (mouseX, mouseY, cos(frameCount/10)*15, cos(frameCount/10)*15); //Firefly fill(50); ellipse(mouseX +2, mouseY, 5, 3); fill(255, 255, 0); ellipse(mouseX, mouseY, 3, 3); } //Firefly Sparkle On Key Press void keyPressed(){ frameRate(3); fill(255, 255, 200, 100); ellipse(mouseX, mouseY, 35, 35); fill(255, 255, 200); triangle(mouseX -2, mouseY, mouseX + 2, mouseY, mouseX, mouseY + 25); triangle(mouseX -2, mouseY, mouseX + 2, mouseY, mouseX, mouseY - 25); triangle(mouseX, mouseY + 2, mouseX, mouseY - 2, mouseX + 25, mouseY); triangle(mouseX, mouseY + 2, mouseX, mouseY - 2, mouseX - 25, mouseY); } // Crow's Glowing Eye on Mouse Click void mouseClicked(){ frameRate(3); fill(255, 0, 0); ellipse(283, 69, 4, 4); fill(255, 0, 0, 100); ellipse(283, 69, 8, 8); fill(255, 0 , 0, 35); ellipse(283, 69, 12, 12); }
